The high-precision vertical center is represented by a wide range of vertical turning centers, which allow processing parts of various sizes.
High precision cartridge spindle.
Possibility of double layout (control of two machines from one CNC, which significantly saves space, facilitates maintenance and increases productivity
| Classification | Unit | PUMA V400 |
|---|---|---|
| Max. processing diameter | mm | 496 |
| Max. workpiece length | mm | 450 Class |
| Standard Chuck Size | inch | 12 |
| Max. Spindle Speed | r/min | 3000 |
| Max. motor power | kW | 22 |
| NC System | – | FANUC / SIEMENS |
| Machining Capability | – | Standards, M, P, 2SP |
| Capability Description | – | M : Milling P : Productivity model 2SP : Twin spindle |
STANDARD EQUIPMENT:
OPTIONS (Optional equipment):
You can get additional information from our managers.
Please note that the manufacturer may change the design and specifications without prior notice.
